WR Linkert Intake Manifold 1952 / 1956 K 1941 / 1952 WR 1954 / 1956 KH

WR Linkert Intake Manifold 1952 / 1956 K 1941 / 1952 WR 1954 / 1956 KH

35-0286
$157.36
$157.36
Shipping calculated at checkout.
Quantity must be 1 or more

Four bolt WR intake manifold for Linkert carburetor is cast iron with zinc plating. NOTE: For WR and K use order correct manifold nuts and seals separately. Installation requires the nipples to be screwed into the cylinder depth so that the manifold alignment is correct. For the float arm installation the center prong of the float arm should have .003 of clearance in order for the arm and needle to move freely.

FITMENT

  • 1952 / 1956 K
  • 1941 / 1952 WR
  • 1954 / 1956 KH

    • TECH NOTES

  • To install the WR manifold on a 45inch cylinder on W and G models the intake manifold nipples must be replaced with #9423-1 larger nipples.
  • Suggested to use with #35-1707 Manifold Nipple Set
  • To be installed on WL models 0.100inch must be machined from eash spigot for a total of 0.200inch overall.
  • Suggested to use with #35-1952 Intake Manifold Nut Set.

    • MEASURMENTS

  • Intake Bore I.D.: 1-9/16 inches

    • ACCESSORY ITEMS

  • 15-0262
  • 8006-2
  • 8007-2
  • 35-0937

    • REPLACEMENT PARTS

  • 9664-8
  • 7104-2

    • Tech Notes

    To be installed on WL models 0.100" must be machined from
